Brakes Parts
02032 PCRV Parts
| No. | Part Number | Part Name | QTY. |
|---|---|---|---|
| 1. | RP3-BK02005 | PCRV/RR | 1 |
| 2. | RP3-BK01006 | PCRV/FR | 1 |
| 3. | 9102004-M6 | Screw, M6-1.0X35mm | 4 |
| 4. | RP3-BK03009 | Brake line bolt M10 × 1.25 | 7 |
| 5. | RP3-BK03010 | Brake line bolt washer M10 × 1.25 | 14 |
